CPU
|
Support AMD Socket AM2/AM2+
|
Chipset
|
AMD RS785 Chipset + SB750 Chipset
|
Memory
|
2 * SODIMM Sockets for un-buffered Dual Channel DDR2 800 SDRAM up to 4 GB
|
Expansion Slots
|
1 * 32-bit PCI slot
1 *MINI PCI-E Connector
|
Storage
|
Embedded SB750 Chipset
4 * Serial ATA2 3Gb/s connectors
Supports HDDs with RAID 0, 1,5,10 functions
|
Audio
|
Realtek ALC662 6-Channel HD Audio CODEC
|
Ethernet LAN
|
Realtek RTL8111DL PCI-E LAN chip for 10/100M LAN / Gigabit LAN
|
USB
|
Embedded 10 * USB 2.0/1.1
|
Special Features
|
Advanced Power Design that supports the latest Socket-AM2+ CPU
“IMAGE IT!” System Backup Software and “ProMagicPLUS!” System Recovery System
|
Rear Panel I / O
|
6 * USB 2.0/1.1 ports
1 * PS2 KB/MS port
1 * RJ-45 port & 2 * e-SATA ports
1 * Audio I / O ports
1 * VGA port
1 * DVI-D port
1 * HDMI port
|
Internal I / O
|
2 * USB 2.0/1.1 headers for 4 USB 2.0 ports
CPU / Chassis Fan connectors;
1 * 4-pin ATX 12V Power connector
1 * 20-pin ATX Power connector
1 * COM hearder
|
Functional
|
ATM, Automation, medical Equipment, Security, Networking, POS, General Application, Gaming Machine, Transportation
|
Temperature
|
Operating within 0~50 centigrade
Storage within -20-85 centigrade
|
BIOS
|
8MB SPI Flash ROM
|
Form Factor
|
Mini ITX Form Factor(17cmx17cm) |
